| 物料号 |
| 139370 6X0,75 |
| 139370 8X1 |
| 139370 10X1 |
| 139370 12X1 |
| 139370 12X1,5 |
| 139370 16X1,5 |
| 139370 18X1,5 |
| 139370 20X1,5 |
公差等级 |
切刃数 Z |
切割角 |
底孔直径 ⌀ 参考值 |
总长度 L |
排屑槽数量 |
柄四边 □ |
柄直径 Ds |
系列 |
螺纹深度 |
螺纹直径 |
螺纹规格 |
螺距 |
ISO 2X 6HX
5
9degrees
5.65mm
80mm
5
3.4mm
4.5mm
Pro Form
18mm
6mm
M6×0.75
0.75mm
| ||||||||||||
ISO 2X 6HX
5
9degrees
7.55mm
90mm
5
4.9mm
6mm
Pro Form
24mm
8mm
M8×1
1mm
| ||||||||||||
ISO 2X 6HX
6
9degrees
9.55mm
90mm
6
5.5mm
7mm
Pro Form
30mm
10mm
M10×1
1mm
| ||||||||||||
ISO 2X 6HX
6
9degrees
11.55mm
100mm
6
7mm
9mm
Pro Form
36mm
12mm
M12×1
1mm
| ||||||||||||
ISO 2X 6HX
6
9degrees
11.35mm
100mm
6
7mm
9mm
Pro Form
36mm
12mm
M12×1.5
1.5mm
| ||||||||||||
ISO 2X 6HX
6
9degrees
15.35mm
100mm
6
9mm
12mm
Pro Form
48mm
16mm
M16×1.5
1.5mm
| ||||||||||||
ISO 2X 6HX
8
9degrees
17.35mm
110mm
8
11mm
14mm
Pro Form
54mm
18mm
M18×1.5
1.5mm
| ||||||||||||
ISO 2X 6HX
8
9degrees
19.35mm
125mm
8
12mm
16mm
Pro Form
60mm
20mm
M20×1.5
1.5mm
|
