| 物料号 |
| 139130 M1 |
| 139130 M1,2 |
| 139130 M1,4 |
| 139130 M1,6 |
| 139130 M1,7 |
| 139130 M2 |
| 139130 M2,3 |
| 139130 M2,5 |
| 139130 M2,6 |
| 139130 M3 |
| 139130 M3,5 |
| 139130 M4 |
| 139130 M5 |
| 139130 M6 |
| 139130 M8 |
| 139130 M10 |
| 139130 M12 |
| 139130 M16 |
公差等级 |
切刃数 Z |
切割角 |
底孔直径 ⌀ 参考值 |
总长度 L |
排屑槽数量 |
柄四边 □ |
柄直径 Ds |
系列 |
螺纹深度 |
螺纹直径 |
螺纹规格 |
螺距 |
ISO 1X 4HX
1
9degrees
0.9mm
40mm
1
2.1mm
2.5mm
Pro Form
1.5mm
1mm
M1
0.25mm
| ||||||||||||
ISO 1X 4HX
1
9degrees
1.1mm
40mm
1
2.1mm
2.5mm
Pro Form
1.8mm
1.2mm
M1.2
0.25mm
| ||||||||||||
ISO 1X 4HX
1
9degrees
1.25mm
40mm
1
2.1mm
2.5mm
Pro Form
2.1mm
1.4mm
M1.4
0.3mm
| ||||||||||||
ISO 2X 6HX
3
9degrees
1.45mm
40mm
3
2.1mm
2.5mm
Pro Form
2.4mm
1.6mm
M1.6
0.35mm
| ||||||||||||
ISO 2X 6HX
3
9degrees
1.55mm
40mm
3
2.1mm
2.5mm
Pro Form
2.55mm
1.7mm
M1.7
0.35mm
| ||||||||||||
ISO 2X 6HX
3
9degrees
1.85mm
45mm
3
2.1mm
2.8mm
Pro Form
3mm
2mm
M2
0.4mm
| ||||||||||||
ISO 2X 6HX
3
9degrees
2.1mm
45mm
3
2.1mm
2.8mm
Pro Form
3.45mm
2.3mm
M2,3
0.4mm
| ||||||||||||
ISO 2X 6HX
3
9degrees
2.3mm
50mm
3
2.1mm
2.8mm
Pro Form
3.75mm
2.5mm
M2.5
0.45mm
| ||||||||||||
ISO 2X 6HX
3
9degrees
2.4mm
50mm
3
2.1mm
2.8mm
Pro Form
3.9mm
2.6mm
M2.6
0.45mm
| ||||||||||||
ISO 2X 6HX
3
9degrees
2.8mm
56mm
3
2.7mm
3.5mm
Pro Form
4.5mm
3mm
M3
0.5mm
| ||||||||||||
ISO 2X 6HX
3
9degrees
3.25mm
56mm
3
3mm
4mm
Pro Form
5.25mm
3.5mm
M3.5
0.6mm
| ||||||||||||
ISO 2X 6HX
4
9degrees
3.7mm
63mm
4
3.4mm
4.5mm
Pro Form
6mm
4mm
M4
0.7mm
| ||||||||||||
ISO 2X 6HX
4
9degrees
4.65mm
70mm
4
4.9mm
6mm
Pro Form
7.5mm
5mm
M5
0.8mm
| ||||||||||||
ISO 2X 6HX
5
9degrees
5.55mm
80mm
5
4.9mm
6mm
Pro Form
9mm
6mm
M6
1mm
| ||||||||||||
ISO 2X 6HX
5
9degrees
7.45mm
90mm
5
6.2mm
8mm
Pro Form
12mm
8mm
M8
1.25mm
| ||||||||||||
ISO 2X 6HX
5
9degrees
9.35mm
100mm
5
8mm
10mm
Pro Form
15mm
10mm
M10
1.5mm
| ||||||||||||
ISO 2X 6HX
5
9degrees
11.2mm
110mm
5
7mm
9mm
Pro Form
18mm
12mm
M12
1.75mm
| ||||||||||||
ISO 2X 6HX
5
9degrees
15.1mm
110mm
5
9mm
12mm
Pro Form
24mm
16mm
M16
2mm
|
