| 物料号 |
| 834000 12,5 |
| 834000 15,2 |
| 834000 16,5 |
| 834000 18,6 |
| 834000 20 |
| 834000 20,5 |
| 834000 22 |
| 834000 22,5 |
| 834000 25,5 |
| 834000 28,3 |
| 834000 30 |
| 834000 32 |
| 834000 32,5 |
| 834000 35 |
| 834000 37 |
| 834000 40,5 |
| 834000 45 |
| 834000 47 |
| 834000 50,5 |
| 834000 54 |
| 834000 60 |
| 834000 63,5 |
| 834000 70 |
| 834000 75 |
| 834000 80 |
冲压头直径（孔直径） |
压紧螺栓 |
压紧螺栓的扳手开口度 |
导管螺纹符合 DIN 40430 |
材料厚度（金属板 St 37） |
符合 DIN EN 60423 的公制螺纹 |
适合加工的不锈钢板最大厚度（取决于强度） |
预钻孔直径 |
12.5mm
M6×30
内六角，规格尺寸 5mm
Pg7
1.5mm
M12×1,5
1mm
7mm
| |||||||
15.2mm
M8×1×35
13mm
Pg9
1.5mm
1mm
9mm
| |||||||
16.5mm
M10×1×45
17mm
1.75mm
M16×1.5
1.25mm
11mm
| |||||||
18.6mm
M10×1×45
17mm
Pg11
1.75mm
1.25mm
11mm
| |||||||
20mm
M10×1×45
17mm
1.75mm
1.25mm
11mm
| |||||||
20.5mm
M10×1×45
17mm
Pg13
1.75mm
M 20×1.5
1.25mm
11mm
| |||||||
22mm
M10×1×45
17mm
1.75mm
1.25mm
11mm
| |||||||
22.5mm
M10×1×45
17mm
Pg16
1.75mm
1.25mm
11mm
| |||||||
25.5mm
M10×1×45
17mm
1.75mm
M25×1.5
1.25mm
11mm
| |||||||
28.3mm
M10×1×55
17mm
Pg21
1.75mm
1.25mm
11mm
| |||||||
30mm
M10×1×55
17mm
1.75mm
1.25mm
11mm
| |||||||
32mm
M10×1×55
17mm
1.75mm
1.25mm
11mm
| |||||||
32.5mm
M16×1.5×55
24mm
2.5mm
M32X1.5
1.75mm
17mm
| |||||||
35mm
M16×1.5×55
24mm
2.5mm
1.75mm
17mm
| |||||||
37mm
M16×1.5×55
24mm
Pg29
2.5mm
1.75mm
17mm
| |||||||
40.5mm
M16×1.5×70
24mm
2.5mm
M40X1.5
1.75mm
17mm
| |||||||
45mm
M16×1.5×70
24mm
2.5mm
1.75mm
17mm
| |||||||
47mm
M20×1.5×70
30mm
Pg36
3mm
2mm
21mm
| |||||||
50.5mm
M 20×1.5×70
30mm
3mm
M50×1.5
2mm
21mm
| |||||||
54mm
M 20×1.5×80
30mm
Pg42
3mm
2mm
21mm
| |||||||
60mm
M 20×1.5×80
30mm
Pg48
3mm
2mm
21mm
| |||||||
63.5mm
M 20×1.5×80
30mm
3mm
M63×1.5
2mm
21mm
| |||||||
70mm
M 20×1.5×90
30mm
3mm
2mm
21mm
| |||||||
75mm
M 20×1.5×90
30mm
3mm
2mm
21mm
| |||||||
80mm
M 20×1.5×90
30mm
3mm
2mm
21mm
|
| 销售价 | 数量 |
