GARANT Master Steel 整体硬质合金高性能钻头 DIN 6535 HA-霍夫曼Hoffmann

商品详情

商品名称：GARANT Master Steel 整体硬质合金高性能钻头 DIN 6535 HA

商品编号：122761 3

提示

容屑槽长度 L_C = L₂ + 1.5 × D_C。
类型 HB 和 HE 与 HA 同价。
类型 HB：以编号 122762 订购。
类型 HE：以编号 122761 + 129100HE 订购。

技术说明

坚固的钻头设计和优化的特殊刃口薄化 实现最佳切屑成形和安全断屑，同时增加进给量。进一步开发的微型结构、凸面切刃形状和锥面打磨额外提高主切刃的稳定性。经过优化的容屑槽几何结构和获得专利的端面刃型确保在钢件和铸件上过程安全地排屑。最新一代高性能涂层。

属性

公差，公称直径	公称直径 D_C	切刃数 Z	总长度 L	排屑槽长度 L_c	推荐最大钻深 L₂	柄直径 D_s	标准	进给量 f，针对抗拉强度 < 1100 N/mm² 的钢件

h7	3mm	2	66mm	28mm	23.5mm	6mm	DIN 6537	0.12mm/rev
h7	3.1mm	2	66mm	28mm	23.4mm	6mm	DIN 6537	0.12mm/rev
h7	3.2mm	2	66mm	28mm	23.2mm	6mm	DIN 6537	0.12mm/rev
h7	3.3mm	2	66mm	28mm	23.1mm	6mm	DIN 6537	0.13mm/rev
h7	3.4mm	2	66mm	28mm	22.9mm	6mm	DIN 6537	0.13mm/rev
h7	3.5mm	2	66mm	28mm	22.8mm	6mm	DIN 6537	0.13mm/rev
h7	3.7mm	2	66mm	28mm	22.5mm	6mm	DIN 6537	0.14mm/rev
h7	3.8mm	2	74mm	36mm	30.3mm	6mm	DIN 6537	0.14mm/rev
h7	3.9mm	2	74mm	36mm	30.2mm	6mm	DIN 6537	0.15mm/rev
h7	4mm	2	74mm	36mm	30mm	6mm	DIN 6537	0.15mm/rev
h7	4.1mm	2	74mm	36mm	29.9mm	6mm	DIN 6537	0.15mm/rev
h7	4.2mm	2	74mm	36mm	29.7mm	6mm	DIN 6537	0.16mm/rev
h7	4.3mm	2	74mm	36mm	29.6mm	6mm	DIN 6537	0.16mm/rev
h7	4.5mm	2	74mm	36mm	29.3mm	6mm	DIN 6537	0.16mm/rev
h7	4.6mm	2	74mm	36mm	29.1mm	6mm	DIN 6537	0.17mm/rev
h7	4.7mm	2	74mm	36mm	29mm	6mm	DIN 6537	0.17mm/rev
h7	4.8mm	2	82mm	44mm	35.8mm	6mm	DIN 6537	0.17mm/rev
h7	4.9mm	2	82mm	44mm	36.7mm	6mm	DIN 6537	0.18mm/rev
h7	5mm	2	82mm	44mm	36.5mm	6mm	DIN 6537	0.18mm/rev
h7	5.1mm	2	82mm	44mm	36.4mm	6mm	DIN 6537	0.18mm/rev
h7	5.2mm	2	82mm	44mm	36.2mm	6mm	DIN 6537	0.18mm/rev
h7	5.3mm	2	82mm	44mm	36.1mm	6mm	DIN 6537	0.19mm/rev
h7	5.5mm	2	82mm	44mm	35.8mm	6mm	DIN 6537	0.19mm/rev
h7	5.6mm	2	82mm	44mm	35.6mm	6mm	DIN 6537	0.2mm/rev
h7	5.7mm	2	82mm	44mm	35.5mm	6mm	DIN 6537	0.2mm/rev
h7	5.8mm	2	82mm	44mm	35.3mm	6mm	DIN 6537	0.2mm/rev
h7	5.9mm	2	82mm	44mm	35.2mm	6mm	DIN 6537	0.2mm/rev
h7	6mm	2	82mm	44mm	35mm	6mm	DIN 6537	0.21mm/rev
h7	6.1mm	2	91mm	53mm	43.9mm	8mm	DIN 6537	0.21mm/rev
h7	6.2mm	2	91mm	53mm	43.7mm	8mm	DIN 6537	0.21mm/rev
h7	6.3mm	2	91mm	53mm	43.6mm	8mm	DIN 6537	0.22mm/rev
h7	6.4mm	2	91mm	53mm	43.4mm	8mm	DIN 6537	0.22mm/rev
h7	6.5mm	2	91mm	53mm	43.3mm	8mm	DIN 6537	0.22mm/rev
h7	6.6mm	2	91mm	53mm	43.1mm	8mm	DIN 6537	0.22mm/rev
h7	9.8mm	2	91mm	53mm	42.8mm	8mm	DIN 6537	0.23mm/rev
h7	6.9mm	2	91mm	53mm	42.7mm	8mm	DIN 6537	0.23mm/rev
h7	7mm	2	91mm	53mm	42.5mm	8mm	DIN 6537	0.23mm/rev
h7	7.2mm	2	91mm	53mm	42.2mm	8mm	DIN 6537	0.24mm/rev
h7	7.3mm	2	91mm	53mm	42.1mm	8mm	DIN 6537	0.24mm/rev
h7	7.5mm	2	91mm	53mm	41.8mm	8mm	DIN 6537	0.25mm/rev
h7	7.8mm	2	91mm	53mm	41.3mm	8mm	DIN 6537	0.25mm/rev
h7	7.9mm	2	91mm	53mm	41.2mm	8mm	DIN 6537	0.26mm/rev
h7	8mm	2	91mm	53mm	41mm	8mm	DIN 6537	0.26mm/rev
h7	8.1mm	2	103mm	61mm	48.9mm	10mm	DIN 6537	0.26mm/rev
h7	8.2mm	2	103mm	61mm	48.7mm	10mm	DIN 6537	0.26mm/rev
h7	8.3mm	2	103mm	61mm	48.6mm	10mm	DIN 6537	0.27mm/rev
h7	8.5mm	2	103mm	61mm	48.3mm	10mm	DIN 6537	0.27mm/rev
h7	8.6mm	2	103mm	61mm	48.1mm	10mm	DIN 6537	0.27mm/rev
h7	8.7mm	2	103mm	61mm	48mm	10mm	DIN 6537	0.28mm/rev
h7	8.8mm	2	103mm	61mm	47.8mm	10mm	DIN 6537	0.28mm/rev
h7	9mm	2	103mm	61mm	47.5mm	10mm	DIN 6537	0.28mm/rev
h7	9.2mm	2	103mm	61mm	47.2mm	10mm	DIN 6537	0.29mm/rev
h7	9.3mm	2	103mm	61mm	47.1mm	10mm	DIN 6537	0.29mm/rev
h7	9.4mm	2	103mm	61mm	46.9mm	10mm	DIN 6537	0.29mm/rev
h7	9.5mm	2	103mm	61mm	46.8mm	10mm	DIN 6537	0.29mm/rev
h7	9.8mm	2	103mm	61mm	46.3mm	10mm	DIN 6537	0.3mm/rev
h7	10mm	2	103mm	61mm	46mm	10mm	DIN 6537	0.3mm/rev
h7	10.2mm	2	118mm	71mm	55.7mm	12mm	DIN 6537	0.31mm/rev
h7	10.3mm	2	118mm	71mm	55.6mm	12mm	DIN 6537	0.31mm/rev
h7	10.5mm	2	118mm	71mm	55.3mm	12mm	DIN 6537	0.32mm/rev
h7	10.8mm	2	118mm	71mm	54.8mm	12mm	DIN 6537	0.32mm/rev
h7	11mm	2	118mm	71mm	54.5mm	12mm	DIN 6537	0.33mm/rev
h7	11.2mm	2	118mm	71mm	54.2mm	12mm	DIN 6537	0.33mm/rev
h7	11.5mm	2	118mm	71mm	53.8mm	12mm	DIN 6537	0.33mm/rev
h7	11.8mm	2	118mm	71mm	53.3mm	12mm	DIN 6537	0.34mm/rev
h7	12mm	2	118mm	71mm	53mm	12mm	DIN 6537	0.34mm/rev
h7	12.2mm	2	124mm	77mm	57.7mm	14mm	DIN 6537	0.35mm/rev
h7	12.5mm	2	124mm	77mm	58.3mm	14mm	DIN 6537	0.35mm/rev
h7	13mm	2	124mm	77mm	57.5mm	14mm	DIN 6537	0.36mm/rev
h7	13.5mm	2	124mm	77mm	56.8mm	14mm	DIN 6537	0.37mm/rev
h7	13.8mm	2	124mm	77mm	56.3mm	14mm	DIN 6537	0.37mm/rev
h7	14mm	2	124mm	77mm	56mm	14mm	DIN 6537	0.38mm/rev
h7	14.2mm	2	133mm	83mm	61.7mm	16mm	DIN 6537	0.38mm/rev
h7	14.5mm	2	133mm	83mm	61.3mm	16mm	DIN 6537	0.38mm/rev
h7	14.8mm	2	133mm	83mm	60.8mm	16mm	DIN 6537	0.39mm/rev
h7	15mm	2	133mm	83mm	60.5mm	16mm	DIN 6537	0.39mm/rev
h7	15.2mm	2	133mm	83mm	60.2mm	16mm	DIN 6537	0.39mm/rev
h7	15.5mm	2	133mm	83mm	59.8mm	16mm	DIN 6537	0.4mm/rev
h7	15.8mm	2	133mm	83mm	59.3mm	16mm	DIN 6537	0.4mm/rev
h7	16mm	2	133mm	83mm	59mm	16mm	DIN 6537	0.4mm/rev
h7	16.5mm	2	143mm	93mm	68.3mm	18mm	DIN 6537	0.41mm/rev
h7	17mm	2	143mm	93mm	67.5mm	18mm	DIN 6537	0.41mm/rev
h7	17.5mm	2	143mm	93mm	66.8mm	18mm	DIN 6537	0.42mm/rev
h7	18mm	2	143mm	93mm	66mm	18mm	DIN 6537	0.42mm/rev
h7	18.5mm	2	155mm	101mm	73.3mm	20mm	DIN 6537	0.43mm/rev
h7	19mm	2	155mm	101mm	72.5mm	20mm	DIN 6537	0.43mm/rev
h7	19.5mm	2	155mm	101mm	71.8mm	20mm	DIN 6537	0.43mm/rev
h7	20mm	2	155mm	101mm	71mm	20mm	DIN 6537	0.44mm/rev
