| 物料号 |
| 206372 6/0,5 |
| 206372 6/0,8 |
| 206372 6/1,0 |
| 206372 6/1,5 |
| 206372 8/0,5 |
| 206372 8/0,8 |
| 206372 8/1,0 |
| 206372 8/1,5 |
| 206372 8/2,0 |
| 206372 8/3,0 |
| 206372 10/0,5 |
| 206372 10/0,8 |
| 206372 10/1,0 |
| 206372 10/1,5 |
| 206372 10/2,0 |
| 206372 10/3,0 |
| 206372 12/0,5 |
| 206372 12/1,0 |
| 206372 12/1,5 |
| 206372 12/2,0 |
| 206372 12/3,0 |
| 206372 16/2,0 |
| 206372 16/3,0 |
修正系数 fz |
刀柄 |
切刃半径 R1 |
切刃直径 DC |
切削刃长度 Lc |
切槽时的最大切割深度 ap max |
切边时的最大切割深度 ap max |
总长度 L |
悬伸长度 L1，包括颈位在内 |
柄直径 Ds |
螺纹升角 |
进给量 fz，针对硬度 < 65 HRC 的钢的仿形铣削 |
颈位直径 D1 |
齿数 Z |
1.25
DIN 6535 HA，带 h6
0.5mm
6mm
7mm
0.3mm
7mm
57mm
21mm
6mm
50degrees
0.048mm
5.5mm
6
| |||||||||||||
1.25
DIN 6535 HA，带 h6
0.8mm
6mm
7mm
0.3mm
7mm
57mm
21mm
6mm
50degrees
0.048mm
5.5mm
6
| |||||||||||||
1.25
DIN 6535 HA，带 h6
1mm
6mm
7mm
0.3mm
7mm
57mm
21mm
6mm
50degrees
0.048mm
5.5mm
6
| |||||||||||||
1.25
DIN 6535 HA，带 h6
1.5mm
6mm
7mm
0.3mm
7mm
57mm
21mm
6mm
50degrees
0.048mm
5.5mm
6
| |||||||||||||
1.25
DIN 6535 HA，带 h6
0.5mm
8mm
9mm
0.4mm
9mm
63mm
27mm
8mm
50degrees
0.06mm
7.4mm
6
| |||||||||||||
1.25
DIN 6535 HA，带 h6
0.8mm
8mm
9mm
0.4mm
9mm
63mm
27mm
8mm
50degrees
0.06mm
7.4mm
6
| |||||||||||||
1.25
DIN 6535 HA，带 h6
1mm
8mm
9mm
0.4mm
9mm
63mm
27mm
8mm
50degrees
0.06mm
7.4mm
6
| |||||||||||||
1.25
DIN 6535 HA，带 h6
1.5mm
8mm
9mm
0.4mm
9mm
63mm
27mm
8mm
50degrees
0.06mm
7.4mm
6
| |||||||||||||
1.25
DIN 6535 HA，带 h6
2mm
8mm
9mm
0.4mm
9mm
63mm
27mm
8mm
50degrees
0.06mm
7.4mm
6
| |||||||||||||
1.25
DIN 6535 HA，带 h6
3mm
8mm
9mm
0.4mm
9mm
63mm
27mm
8mm
50degrees
0.06mm
7.4mm
6
| |||||||||||||
1.25
DIN 6535 HA，带 h6
0.5mm
10mm
11mm
0.5mm
11mm
72mm
32mm
10mm
50degrees
0.07mm
9.2mm
6
| |||||||||||||
1.25
DIN 6535 HA，带 h6
0.8mm
10mm
11mm
0.5mm
11mm
72mm
32mm
10mm
50degrees
0.07mm
9.2mm
6
| |||||||||||||
1.25
DIN 6535 HA，带 h6
1mm
10mm
11mm
0.5mm
11mm
72mm
32mm
10mm
50degrees
0.07mm
9.2mm
6
| |||||||||||||
1.25
DIN 6535 HA，带 h6
1.5mm
10mm
11mm
0.5mm
11mm
72mm
32mm
10mm
50degrees
0.07mm
9.2mm
6
| |||||||||||||
1.25
DIN 6535 HA，带 h6
2mm
10mm
11mm
0.5mm
11mm
72mm
32mm
10mm
50degrees
0.07mm
9.2mm
6
| |||||||||||||
1.25
DIN 6535 HA，带 h6
3mm
10mm
11mm
0.5mm
11mm
72mm
32mm
10mm
50degrees
0.07mm
9.2mm
6
| |||||||||||||
1.25
DIN 6535 HA，带 h6
0.5mm
12mm
12mm
0.6mm
12mm
83mm
38mm
12mm
50degrees
0.08mm
11mm
6
| |||||||||||||
1.25
DIN 6535 HA，带 h6
1mm
12mm
12mm
0.6mm
12mm
83mm
38mm
12mm
50degrees
0.08mm
11mm
6
| |||||||||||||
1.25
DIN 6535 HA，带 h6
1.5mm
12mm
12mm
0.6mm
12mm
83mm
38mm
12mm
50degrees
0.08mm
11mm
6
| |||||||||||||
1.25
DIN 6535 HA，带 h6
2mm
12mm
12mm
0.6mm
12mm
83mm
38mm
12mm
50degrees
0.08mm
11mm
6
| |||||||||||||
1.25
DIN 6535 HA，带 h6
3mm
12mm
12mm
0.6mm
12mm
83mm
38mm
12mm
50degrees
0.08mm
11mm
6
| |||||||||||||
1.25
DIN 6535 HA，带 h6
2mm
16mm
16mm
0.8mm
16mm
92mm
44mm
16mm
50degrees
0.09mm
15mm
6
| |||||||||||||
1.25
DIN 6535 HA，带 h6
3mm
16mm
16mm
0.8mm
16mm
92mm
44mm
16mm
50degrees
0.09mm
15mm
6
|
| 销售价 | 数量 |
