| 物料号 |
| 206162 0,8/0,08 |
| 206162 1,2/0,12 |
| 206162 1,5/0,15 |
| 206162 1/0,1 |
| 206162 1/0,25 |
| 206162 2/0,2 |
| 206162 2/0,5 |
| 206162 3/0,3 |
| 206162 3/0,5 |
| 206162 3/1,0 |
| 206162 4/1,0 |
| 206162 6/1,0 |
| 206162 6/2,0 |
| 206162 8/1,0 |
| 206162 8/2,0 |
| 206162 10/1,5 |
| 206162 12/1,5 |
L2 |
修正系数 fz |
刀柄 |
切刃半径 R1 |
切刃直径 DC |
切削刃长度 Lc |
切槽时的最大切割深度 ap max |
切边时的最大切割深度 ap max |
总长度 L |
悬伸长度 L1，包括颈位在内 |
最大柄部避空直径 D6 |
柄直径 Ds |
螺纹升角 |
进给量 fz，针对硬度 < 65 HRC 的钢的仿形铣削 |
进给量 fz，针对硬度 < 65 HRC 的钢的修边加工 |
颈位直径 D1 |
齿数 Z |
27mm
1.25
DIN 6535 HA，带 h6
0.08mm
0.8mm
1mm
0.04mm
1mm
75mm
1.6mm
2.1mm
3mm
30degrees
0.005mm
0.005mm
0.75mm
2
| ||||||||||||||||
27mm
1.25
DIN 6535 HA，带 h6
0.12mm
1.2mm
1.4mm
0.06mm
1.4mm
75mm
2.4mm
2.5mm
3mm
30degrees
0.005mm
0.005mm
1.15mm
2
| ||||||||||||||||
27mm
1.25
DIN 6535 HA，带 h6
0.15mm
1.5mm
1.8mm
0.075mm
1.8mm
75mm
3mm
2.7mm
3mm
30degrees
0.005mm
0.005mm
1.45mm
2
| ||||||||||||||||
27mm
1.25
DIN 6535 HA，带 h6
0.1mm
1mm
1.2mm
0.05mm
1.2mm
75mm
2mm
2.3mm
3mm
30degrees
0.005mm
0.005mm
0.95mm
2
| ||||||||||||||||
40mm
1.25
DIN 6535 HA，带 h6
0.25mm
1mm
2mm
0.05mm
2mm
80mm
4mm
2.7mm
6mm
30degrees
0.005mm
0.005mm
0.85mm
2
| ||||||||||||||||
27mm
1.25
DIN 6535 HA，带 h6
0.2mm
2mm
2.4mm
0.1mm
2.4mm
75mm
4mm
3mm
3mm
30degrees
0.005mm
0.005mm
1.95mm
2
| ||||||||||||||||
40mm
1.25
DIN 6535 HA，带 h6
0.5mm
2mm
2mm
0.1mm
2mm
80mm
8mm
3.5mm
6mm
30degrees
0.005mm
0.005mm
1.8mm
2
| ||||||||||||||||
27mm
1.25
DIN 6535 HA，带 h6
0.3mm
3mm
3.6mm
0.15mm
3.6mm
75mm
6mm
4mm
4mm
30degrees
0.019mm
0.019mm
2.95mm
2
| ||||||||||||||||
40mm
1.25
DIN 6535 HA，带 h6
0.5mm
3mm
2mm
0.15mm
2mm
80mm
12mm
4.3mm
6mm
30degrees
0.019mm
0.019mm
2.8mm
2
| ||||||||||||||||
40mm
1.25
DIN 6535 HA，带 h6
1mm
3mm
2mm
0.15mm
2mm
80mm
12mm
4.3mm
6mm
30degrees
0.019mm
0.019mm
2.8mm
2
| ||||||||||||||||
40mm
1.25
DIN 6535 HA，带 h6
1mm
4mm
3mm
0.2mm
3mm
80mm
16mm
5.1mm
6mm
30degrees
0.019mm
0.019mm
3.8mm
2
| ||||||||||||||||
50mm
1.25
DIN 6535 HA，带 h6
1mm
6mm
4mm
0.3mm
4mm
100mm
25mm
7.1mm
8mm
30degrees
0.048mm
0.048mm
5.8mm
2
| ||||||||||||||||
50mm
1.25
DIN 6535 HA，带 h6
2mm
6mm
4mm
0.3mm
4mm
100mm
25mm
7.1mm
8mm
30degrees
0.048mm
0.048mm
5.8mm
2
| ||||||||||||||||
60mm
1.25
DIN 6535 HA，带 h6
1mm
8mm
4mm
0.4mm
4mm
120mm
32mm
9.3mm
10mm
30degrees
0.06mm
0.06mm
7.8mm
2
| ||||||||||||||||
60mm
1.25
DIN 6535 HA，带 h6
2mm
8mm
4mm
0.4mm
4mm
120mm
32mm
9.3mm
10mm
30degrees
0.06mm
0.06mm
7.8mm
2
| ||||||||||||||||
80mm
1.25
DIN 6535 HA，带 h6
1.5mm
10mm
6mm
0.5mm
6mm
160mm
40mm
11.9mm
12mm
30degrees
0.07mm
0.07mm
9.8mm
2
| ||||||||||||||||
100mm
1.25
DIN 6535 HA，带 h6
1.5mm
12mm
8mm
0.6mm
8mm
200mm
50mm
14.5mm
16mm
30degrees
0.08mm
0.08mm
11.8mm
2
|
| 销售价 | 数量 |
