| 物料号 |
| 206040 3/0,3 |
| 206040 4/0,3 |
| 206040 4/1,0 |
| 206040 5/0,3 |
| 206040 5/1,0 |
| 206040 6/0,3 |
| 206040 6/1,0 |
| 206040 6/2,0 |
| 206040 8/0,3 |
| 206040 8/1,0 |
| 206040 8/2,0 |
| 206040 10/0,3 |
| 206040 10/1,0 |
| 206040 10/1,5 |
| 206040 10/3,0 |
| 206040 12/1,0 |
| 206040 12/1,5 |
| 206040 12/2,5 |
| 206040 12/4,0 |
| 206040 16/1,0 |
| 206040 16/2,0 |
| 206040 16/2,5 |
| 206040 16/5,0 |
| 206040 20/5,0 |
修正系数 fz |
刀柄 |
切刃半径 R1 |
切刃直径 DC |
切削刃长度 Lc |
切割深度 ap min |
切槽时的最大切割深度 ap max |
切边时的最大切割深度 ap max |
总长度 L |
悬伸长度 L1，包括颈位在内 |
柄直径 Ds |
螺纹升角 |
进给量 fz，针对短切屑铝合金的仿形铣削 |
进给量 fz，针对短切屑铝合金的修边加工 |
颈位直径 D1 |
齿数 Z |
1.25
DIN 6535 HA，带 h6
0.3mm
3mm
4mm
0.15mm
4mm
50mm
14mm
3mm
30degrees
0.011mm
0.01mm
2.7mm
2
| |||||||||||||||
1.25
DIN 6535 HA，带 h6
0.3mm
4mm
5mm
0.2mm
5mm
50mm
16mm
4mm
30degrees
0.023mm
0.02mm
3.7mm
2
| |||||||||||||||
1.25
DIN 6535 HA，带 h6
1mm
4mm 4mm
5mm 5mm
1mm
0.2mm 0.2mm
5mm 5mm
50mm 50mm
16mm
4mm 4mm
30degrees
0.023mm 0.023mm
0.02mm
3.7mm 3.7mm
2
| |||||||||||||||
1.25
DIN 6535 HA，带 h6
0.3mm
5mm
6mm
0.25mm
6mm
54mm
18mm
5mm
30degrees
0.023mm
0.02mm
4.6mm
2
| |||||||||||||||
1.25 1.25
DIN 6535 HA，带 h6 DIN 6535 HA，带 h6
1mm 1mm
5mm 5mm
6mm
1mm
0.25mm
6mm 6mm
54mm 54mm
18mm
5mm 5mm
30degrees 30degrees
0.023mm
0.02mm 0.02mm
4.6mm 4.6mm
2 2
| |||||||||||||||
1.25
DIN 6535 HA，带 h6
0.3mm
6mm
7mm
0.3mm
7mm
57mm
21mm
6mm
30degrees
0.034mm
0.03mm
5.5mm
2
| |||||||||||||||
1.25
DIN 6535 HA，带 h6
1mm
6mm
7mm
0.3mm
7mm
57mm
21mm
6mm
30degrees
0.034mm
0.03mm
5.5mm
2
| |||||||||||||||
1.25
DIN 6535 HA，带 h6
2mm
6mm
7mm
0.3mm
7mm
57mm
21mm
6mm
30degrees
0.034mm
0.03mm
5.5mm
2
| |||||||||||||||
1.25
DIN 6535 HA，带 h6
0.3mm
8mm
9mm
0.4mm
9mm
63mm
27mm
8mm
30degrees
0.045mm
0.04mm
7.4mm
2
| |||||||||||||||
1.25
DIN 6535 HA，带 h6
1mm
8mm
9mm
0.4mm
9mm
63mm
27mm
8mm
30degrees
0.045mm
0.04mm
7.4mm
2
| |||||||||||||||
1.25
DIN 6535 HA，带 h6
2mm
8mm
9mm
0.4mm
9mm
63mm
27mm
8mm
30degrees
0.045mm
0.04mm
7.4mm
2
| |||||||||||||||
1.25
DIN 6535 HA，带 h6
0.3mm
10mm
11mm
0.5mm
11mm
72mm
32mm
10mm
30degrees
0.056mm
0.05mm
9.2mm
2
| |||||||||||||||
1.25 1.25
DIN 6535 HA，带 h6 DIN 6535 HA，带 h6
1mm
10mm 10mm
11mm
1mm
0.5mm
11mm 11mm
72mm
32mm 32mm
10mm 10mm
30degrees
0.056mm 0.056mm
0.05mm 0.05mm
9.2mm
2 2
| |||||||||||||||
1.25
DIN 6535 HA，带 h6
1.5mm
10mm
11mm
0.5mm
11mm
72mm
32mm
10mm
30degrees
0.056mm
0.05mm
9.2mm
2
| |||||||||||||||
1.25
DIN 6535 HA，带 h6
3mm
10mm
11mm
0.5mm
11mm
72mm
32mm
10mm
30degrees
0.056mm
0.05mm
9.2mm
2
| |||||||||||||||
1.25 1.25
DIN 6535 HA，带 h6
1mm
12mm
12mm 12mm
1mm
0.6mm 0.6mm
12mm 12mm
83mm
38mm 38mm
12mm 12mm
30degrees 30degrees
0.079mm
0.07mm
11mm 11mm
2 2
| |||||||||||||||
1.25
DIN 6535 HA，带 h6
1.5mm
12mm
12mm
0.6mm
12mm
83mm
38mm
12mm
30degrees
0.079mm
0.07mm
11mm
2
| |||||||||||||||
1.25 1.25
DIN 6535 HA，带 h6
2.5mm 2.5mm
12mm 12mm
12mm
1mm
0.6mm
12mm
83mm
38mm 38mm
12mm
30degrees 30degrees
0.079mm 0.079mm
0.07mm 0.07mm
11mm 11mm
2 2
| |||||||||||||||
1.25
DIN 6535 HA，带 h6
4mm
12mm
12mm
0.6mm
12mm
83mm
38mm
12mm
30degrees
0.079mm
0.07mm
11mm
2
| |||||||||||||||
1.25
DIN 6535 HA，带 h6
1mm
16mm 16mm
16mm 16mm
1mm
0.8mm
16mm 16mm
92mm
44mm
16mm 16mm
30degrees 30degrees
0.1mm 0.1mm
0.09mm 0.09mm
15mm
2 2
| |||||||||||||||
1.25
DIN 6535 HA，带 h6
2mm
16mm
16mm
0.8mm
16mm
92mm
44mm
16mm
30degrees
0.1mm
0.09mm
15mm
2
| |||||||||||||||
1.25
DIN 6535 HA，带 h6 DIN 6535 HA，带 h6
2.5mm 2.5mm
16mm 16mm
16mm 16mm
1mm
0.8mm
16mm
92mm
44mm 44mm
16mm 16mm
30degrees 30degrees
0.1mm
0.09mm 0.09mm
15mm 15mm
2
| |||||||||||||||
1.25
DIN 6535 HA，带 h6
5mm
16mm
16mm
0.8mm
16mm
92mm
44mm
16mm
30degrees
0.1mm
0.09mm
15mm
2
| |||||||||||||||
1.25 1.25
DIN 6535 HA，带 h6 DIN 6535 HA，带 h6
5mm 5mm
20mm 20mm
20mm 20mm
1mm
0.8mm 0.8mm
20mm
104mm 104mm
54mm
20mm
30degrees 30degrees
0.15mm
0.12mm 0.12mm
19mm 19mm
2
|
