| 物料号 |
| 207280 1,5/6 |
| 207280 1/6 |
| 207280 2,5/6 |
| 207280 2/6 |
| 207280 3 |
| 207280 3/6 |
| 207280 4 |
| 207280 4/6 |
| 207280 5 |
| 207280 5/6 |
| 207280 6 |
| 207280 8 |
| 207280 10 |
| 207280 12 |
| 207280 16 |
| 207280 20 |
vc 的修正系数 |
仿形加工时的最大切削深度 ap max |
修正系数 fz |
切刃直径 DC |
切削刃长度 Lc |
切边时的最大切割深度 ap max |
半径 R |
总长度 L |
柄直径 Ds |
螺纹升角 |
进给量 fz，针对抗拉强度 < 1100 N/mm2 的钢的仿形铣削 |
进给量 fz，针对抗拉强度 < 1100 N/mm2 的钢的修边加工 |
齿数 Z |
0.045mm
1.25
1.5mm
3mm
3mm
0.75mm
80mm
6mm
30degrees
0.007mm
0.006mm
2
| ||||||||||||
1.25
0.03mm
1.25
1mm
2mm
2mm
0.5mm
80mm
6mm
30degrees
0.007mm
0.006mm
2
| ||||||||||||
0.075mm
1.25
2.5mm
5mm
5mm
1.25mm
80mm
6mm
30degrees
0.011mm
0.0095mm
2
| ||||||||||||
1.25
0.06mm
1.25
2mm
4mm
4mm
1mm
80mm
6mm
30degrees
0.011mm
0.0095mm
2
| ||||||||||||
0.09mm
1.25
3mm
5mm
5mm
1.5mm
75mm
3mm
30degrees
0.011mm
0.0095mm
2
| ||||||||||||
1.25
0.09mm
1.25
3mm
5mm
5mm
1.5mm
80mm
6mm
30degrees
0.011mm
0.0095mm
2
| ||||||||||||
0.12mm
1.25
4mm
8mm
8mm
2mm
75mm
4mm
30degrees
0.037mm
0.032mm
2
| ||||||||||||
1.25
0.12mm
1.25
4mm
8mm
8mm
2mm
80mm
6mm
30degrees
0.037mm
0.032mm
2
| ||||||||||||
0.15mm
1.25
5mm
9mm
9mm
2.5mm
75mm
5mm
30degrees
0.037mm
0.032mm
2
| ||||||||||||
1.25
0.15mm
1.25
5mm
9mm
9mm
2.5mm
100mm
6mm
30degrees
0.037mm
0.032mm
2
| ||||||||||||
0.18mm
1.25
6mm
10mm
10mm
3mm
100mm
6mm
30degrees
0.051mm
0.044mm
2
| ||||||||||||
0.24mm
1.25
8mm
12mm
12mm
4mm
100mm
8mm
30degrees
0.06mm
0.052mm
2
| ||||||||||||
0.3mm
1.25
10mm
14mm
14mm
5mm
100mm
10mm
30degrees
0.071mm
0.062mm
2
| ||||||||||||
0.36mm
1.25
12mm
16mm
16mm
6mm
100mm
12mm
30degrees
0.084mm
0.073mm
2
| ||||||||||||
0.48mm
1.25
16mm
22mm
22mm
8mm
150mm
16mm
30degrees
0.117mm
0.102mm
2
| ||||||||||||
0.6mm
1.25
20mm
26mm
26mm
10mm
150mm
20mm
30degrees
0.138mm
0.12mm
2
|
