| 物料号 |
| 303141 M8X50 |
| 303141 M10X50 |
| 303141 M10X100 |
| 303141 M12X50 |
| 303141 M12X100 |
| 303141 M16X50 |
| 303141 M16X100 |
| 303141 M16X150 |
L2 |
外径 D |
安装孔直径 D1 公差 IT6 |
悬伸长度 A 尺寸 |
有效长度 L1 |
直径 D2 |
5mm
23mm
8.5mm
88mm
50mm
13mm
| |||||
5mm
23mm
10.5mm
88mm
50mm
18mm
| |||||
10mm
32mm
10.5mm
138mm
100mm
18mm
| |||||
10mm
24mm
12.5mm
88mm
50mm
21mm
| |||||
10mm
33mm
12.5mm
138mm
100mm
21mm
| |||||
10mm
29mm
17mm
88mm
50mm
29mm
| |||||
10mm
36mm
17mm
138mm
100mm
29mm
| |||||
10mm
42.5mm
17mm
188mm
150mm
29mm
|
