| 物料号 |
| 206211 6/0,5 |
| 206211 6/1,0 |
| 206211 8/0,5 |
| 206211 8/1,0 |
| 206211 8/2,0 |
| 206211 10/0,5 |
| 206211 10/1,0 |
| 206211 10/2,0 |
| 206211 10/3,0 |
| 206211 12/0,5 |
| 206211 12/1,0 |
| 206211 12/2,0 |
| 206211 12/3,0 |
| 206211 16/2,0 |
| 206211 16/3,0 |
| 206211 16/4,0 |
| 206211 20/2,0 |
| 206211 20/3,0 |
| 206211 20/4,0 |
修正系数 fz |
刀柄 |
刀柄形状 |
切刃半径 R1 |
切刃直径 DC |
切削刃长度 Lc |
切屑平均厚度 hmax，针对短切屑铝合金的 TPC 铣削加工 |
切边时的最大切割深度 ap max |
带柄情况下的动平衡精度 |
总长度 L |
悬伸长度 L1，包括颈位在内 |
最大切弧角 |
柄直径 Ds |
螺纹升角 |
颈位直径 D1 |
齿数 Z |
3
DIN 6535 HA，带 h6
HA
0.5mm
6mm
25mm
0.032mm
25mm
G 2.5，带 HA
71mm
30mm
40.54degrees
6mm
45degrees
5.7mm
3
| |||||||||||||||
3
DIN 6535 HA，带 h6
HA
1mm
6mm
25mm
0.032mm
25mm
G 2.5，带 HA
71mm
30mm
40.54degrees
6mm
45degrees
5.7mm
3
| |||||||||||||||
3
DIN 6535 HA，带 h6
HA
0.5mm
8mm
33mm
0.045mm
33mm
G 2.5，带 HA
80mm
40mm
40.54degrees
8mm
45degrees
7.4mm
3
| |||||||||||||||
3
DIN 6535 HA，带 h6
HA
1mm
8mm
33mm
0.045mm
33mm
G 2.5，带 HA
80mm
40mm
40.54degrees
8mm
45degrees
7.4mm
3
| |||||||||||||||
3
DIN 6535 HA，带 h6
HA
2mm
8mm
33mm
0.045mm
33mm
G 2.5，带 HA
80mm
40mm
40.54degrees
8mm
45degrees
7.4mm
3
| |||||||||||||||
3
DIN 6535 HA，带 h6
HA
0.5mm
10mm
41mm
0.055mm
41mm
G 2.5，带 HA
95mm
50mm
40.54degrees
10mm
45degrees
9.2mm
3
| |||||||||||||||
3
DIN 6535 HA，带 h6
HA
1mm
10mm
41mm
0.055mm
41mm
G 2.5，带 HA
95mm
50mm
40.54degrees
10mm
45degrees
9.2mm
3
| |||||||||||||||
3
DIN 6535 HA，带 h6
HA
2mm
10mm
41mm
0.055mm
41mm
G 2.5，带 HA
95mm
50mm
40.54degrees
10mm
45degrees
9.2mm
3
| |||||||||||||||
3
DIN 6535 HA，带 h6
HA
3mm
10mm
41mm
0.055mm
41mm
G 2.5，带 HA
95mm
50mm
40.54degrees
10mm
45degrees
9.2mm
3
| |||||||||||||||
3
DIN 6535 HA，带 h6
HA
0.5mm
12mm
49mm
0.08mm
49mm
G 2.5，带 HA
109mm
60mm
40.54degrees
12mm
45degrees
11mm
3
| |||||||||||||||
3
DIN 6535 HA，带 h6
HA
1mm
12mm
49mm
0.08mm
49mm
G 2.5，带 HA
109mm
60mm
40.54degrees
12mm
45degrees
11mm
3
| |||||||||||||||
3
DIN 6535 HA，带 h6
HA
2mm
12mm
49mm
0.08mm
49mm
G 2.5，带 HA
109mm
60mm
40.54degrees
12mm
45degrees
11mm
3
| |||||||||||||||
3
DIN 6535 HA，带 h6
HA
3mm
12mm
49mm
0.08mm
49mm
G 2.5，带 HA
109mm
60mm
40.54degrees
12mm
45degrees
11mm
3
| |||||||||||||||
3
DIN 6535 HB，带 h6
HB
2mm
16mm
65mm
0.095mm
65mm
G 2.5，带 HB
132mm
80mm
40.54degrees
16mm
45degrees
15mm
3
| |||||||||||||||
3
DIN 6535 HB，带 h6
HB
3mm
16mm
65mm
0.095mm
65mm
G 2.5，带 HB
132mm
80mm
40.54degrees
16mm
45degrees
15mm
3
| |||||||||||||||
3
DIN 6535 HB，带 h6
HB
4mm
16mm
65mm
0.095mm
65mm
G 2.5，带 HB
132mm
80mm
40.54degrees
16mm
45degrees
15mm
3
| |||||||||||||||
3
DIN 6535 HB，带 h6
HB
2mm
20mm
82mm
0.125mm
82mm
G 2.5，带 HB
154mm
100mm
40.54degrees
20mm
45degrees
19mm
3
| |||||||||||||||
3
DIN 6535 HB，带 h6
HB
3mm
20mm
82mm
0.125mm
82mm
G 2.5，带 HB
154mm
100mm
40.54degrees
20mm
45degrees
19mm
3
| |||||||||||||||
3
DIN 6535 HB，带 h6
HB
4mm
20mm
82mm
0.125mm
82mm
G 2.5，带 HB
154mm
100mm
40.54degrees
20mm
45degrees
19mm
3
|
