| 物料号 |
| 206075 6/0,3 |
| 206075 6/1,0 |
| 206075 8/0,3 |
| 206075 8/1,0 |
| 206075 8/2,0 |
| 206075 10/0,3 |
| 206075 10/3,0 |
| 206075 12/1,5 |
| 206075 12/2,5 |
| 206075 12/4,0 |
| 206075 16/2,0 |
| 206075 16/2,5 |
修正系数 fz |
刀柄 |
切刃半径 R1 |
切刃直径 DC |
切削刃长度 Lc |
切割深度 ap min |
切槽时的最大切割深度 ap max |
切边时的最大切割深度 ap max |
总长度 L |
悬伸长度 L1，包括颈位在内 |
柄直径 Ds |
螺纹升角 |
进给量 fz，针对短切屑铝合金的仿形铣削 |
进给量 fz，针对短切屑铝合金的修边加工 |
颈位直径 D1 |
齿数 Z |
1.25
DIN 6535 HA，带 h6
0.3mm
6mm
7mm
0.3mm
7mm
120mm
80mm
6mm
30degrees
0.034mm
0.03mm
5.5mm
2
| |||||||||||||||
1.25
DIN 6535 HA，带 h6
1mm
6mm
7mm
0.3mm
7mm
120mm
80mm
6mm
30degrees
0.034mm
0.03mm
5.5mm
2
| |||||||||||||||
1.25
DIN 6535 HA，带 h6
0.3mm
8mm
9mm
0.4mm
9mm
130mm
90mm
8mm
30degrees
0.045mm
0.04mm
7.4mm
2
| |||||||||||||||
1.25
DIN 6535 HA，带 h6
1mm
8mm
9mm
0.4mm
9mm
130mm
90mm
8mm
30degrees
0.045mm
0.04mm
7.4mm
2
| |||||||||||||||
1.25
DIN 6535 HA，带 h6
2mm
8mm
9mm
0.4mm
9mm
130mm
90mm
8mm
30degrees
0.045mm
0.04mm
7.4mm
2
| |||||||||||||||
1.25
DIN 6535 HA，带 h6
0.3mm
10mm
11mm
0.5mm
11mm
150mm
110mm
10mm
30degrees
0.056mm
0.05mm
9.2mm
2
| |||||||||||||||
1.25
DIN 6535 HA，带 h6
3mm
10mm
11mm
0.5mm
11mm
150mm
110mm
10mm
30degrees
0.056mm
0.05mm
9.2mm
2
| |||||||||||||||
1.25
DIN 6535 HA，带 h6
1.5mm
12mm
12mm
0.6mm
12mm
160mm
115mm
12mm
30degrees
0.079mm
0.07mm
11mm
2
| |||||||||||||||
1.25 1.25
DIN 6535 HA，带 h6 DIN 6535 HA，带 h6
2.5mm 2.5mm
12mm
12mm 12mm
1mm
0.6mm 0.6mm
12mm 12mm
160mm
115mm
12mm
30degrees
0.079mm 0.079mm
0.07mm 0.07mm
11mm
2
| |||||||||||||||
1.25
DIN 6535 HA，带 h6
4mm
12mm
12mm
0.6mm
12mm
160mm
115mm
12mm
30degrees
0.079mm
0.07mm
11mm
2
| |||||||||||||||
1.25
DIN 6535 HA，带 h6
2mm
16mm
16mm
0.8mm
16mm
200mm
140mm
16mm
30degrees
0.1mm
0.09mm
15mm
2
| |||||||||||||||
1.25 1.25
DIN 6535 HA，带 h6 DIN 6535 HA，带 h6
2.5mm 2.5mm
16mm 16mm
16mm 16mm
1mm
0.8mm
16mm
200mm
140mm 140mm
16mm
30degrees
0.1mm
0.09mm 0.09mm
15mm 15mm
2 2
|
| 销售价 | 数量 |
