HOLEX孔加工高速钢麻花钻 N 116320-霍夫曼Hoffmann

商品详情

商品名称：HOLEX孔加工高速钢麻花钻 N 116320

商品编号：116320 70

技术说明

表面经过特殊处理，可减少积屑瘤产生并改善排屑。

提示

适用于带 MK 刀柄的刀具的变径套参见编号 343000-343530。

推荐

最大孔深：
L₂ = L_C- 1.5 × D_C。

技术参数

螺纹升角

20-30degrees

型号

涂层

没有涂层

刀具材料

HSS

刀柄

莫氏锥

内冷式

否

属性

公差，公称直径

公称直径 D_C

70mm

切刃数 Z

2 2

总长度 L

437mm 437mm

排屑槽长度 L_c

250mm

推荐最大钻深 L₂

145mm

标准

DIN 345

莫氏锥柄 MK 尺寸

进给量 f，针对抗拉强度 < 750?N/mm² 的钢件

0.4mm/rev

进给量 f，针对抗拉强度 < 750 N/mm² 的钢件

0.4mm/rev

顶角

118degrees 118degrees

应用

钢材抗拉强度 < 900 N/mm²

有条件适用

钢材抗拉强度 < 750 N/mm²

适用

油

适用

钢材抗拉强度 < 500 N/mm²

适用

灰铸铁（球墨铸铁）

有条件适用

湿，最大

适用

h8	13mm	2	182mm	101mm	81.5mm	DIN 345	1		0.16mm/rev	118degrees
h8	13.5mm	2	189mm	108mm	87.8mm	DIN 345	1		0.16mm/rev	118degrees
h8	13.75mm	2	189mm	108mm	87.4mm	DIN 345	1		0.16mm/rev	118degrees
h8	14mm	2	189mm	108mm	87mm	DIN 345	1		0.16mm/rev	118degrees
h8	14.5mm	2	212mm	114mm	92.3mm	DIN 345	2		0.16mm/rev	118degrees
h8	14.25mm	2	212mm	114mm	92.6mm	DIN 345	2		0.16mm/rev	118degrees
h8	15mm	2	212mm	114mm	91.5mm	DIN 345	2		0.16mm/rev	118degrees
h8	15.5mm	2	218mm	120mm	96.8mm	DIN 345	2		0.16mm/rev	118degrees
h8	15.25mm	2	218mm	120mm	97.1mm	DIN 345	2		0.16mm/rev	118degrees
h8	15.75mm	2	218mm	120mm	96.4mm	DIN 345	2		0.16mm/rev	118degrees
h8	16mm	2	218mm	120mm	96mm	DIN 345	2		0.2mm/rev	118degrees
h8	16.5mm	2	223mm	125mm	100.3mm	DIN 345	2		0.2mm/rev	118degrees
h8	16.25mm	2	223mm	125mm	100.6mm	DIN 345	2		0.2mm/rev	118degrees
h8	16.75mm	2	223mm	125mm	99.9mm	DIN 345	2		0.2mm/rev	118degrees
h8	17mm	2	223mm	125mm	99.5mm	DIN 345	2		0.2mm/rev	118degrees
h8	17.5mm	2	228mm	130mm	103.8mm	DIN 345	2		0.2mm/rev	118degrees
h8	17.25mm	2	228mm	130mm	104.1mm	DIN 345	2		0.2mm/rev	118degrees
h8	17.75mm	2	228mm	130mm	103.4mm	DIN 345	2		0.2mm/rev	118degrees
h8	18mm	2	228mm	130mm	103mm	DIN 345	2		0.2mm/rev	118degrees
h8	18.5mm	2	233mm	135mm	107.3mm	DIN 345	2		0.2mm/rev	118degrees
h8	19mm	2	233mm	135mm	106.5mm	DIN 345	2		0.2mm/rev	118degrees
h8	19.5mm	2	238mm	140mm	110.8mm	DIN 345	2		0.2mm/rev	118degrees
h8	19.75mm	2	238mm	140mm	110.4mm	DIN 345	2		0.2mm/rev	118degrees
h8	20mm	2	238mm	140mm	110mm	DIN 345	2		0.2mm/rev	118degrees
h8	20.5mm	2	243mm	145mm	114.3mm	DIN 345	2		0.2mm/rev	118degrees
h8	21mm	2	243mm	145mm	113.5mm	DIN 345	2		0.2mm/rev	118degrees
h8	21.5mm	2	248mm	150mm	117.8mm	DIN 345	2		0.2mm/rev	118degrees
h8	21.75mm	2	248mm	150mm	117.4mm	DIN 345	2		0.2mm/rev	118degrees
h8	22mm	2	248mm	150mm	117mm	DIN 345	2		0.2mm/rev	118degrees
h8	22.5mm	2	253mm	155mm	121.3mm	DIN 345	2		0.2mm/rev	118degrees
h8	23mm	2	253mm	155mm	120.5mm	DIN 345	2		0.2mm/rev	118degrees
h8	23.5mm	2	276mm	155mm	119.8mm	DIN 345	3		0.2mm/rev	118degrees
h8	24mm	2	281mm	160mm	124mm	DIN 345	3		0.2mm/rev	118degrees
h8	24.5mm	2	281mm	160mm	123.3mm	DIN 345	3		0.2mm/rev	118degrees
h8	25mm	2	281mm	160mm	122.5mm	DIN 345	3		0.25mm/rev	118degrees
h8	25.5mm	2	286mm	165mm	126.8mm	DIN 345	3		0.25mm/rev	118degrees
h8	26mm	2	286mm	165mm	126mm	DIN 345	3		0.25mm/rev	118degrees
h8	26.5mm	2	286mm	165mm	125.3mm	DIN 345	3		0.25mm/rev	118degrees
h8	27mm	2	291mm	170mm	129.5mm	DIN 345	3		0.25mm/rev	118degrees
h8	27.5mm	2	291mm	170mm	128.8mm	DIN 345	3		0.25mm/rev	118degrees
h8	28mm	2	291mm	170mm	128mm	DIN 345	3		0.25mm/rev	118degrees
h8	28.5mm	2	296mm	175mm	132.3mm	DIN 345	3		0.25mm/rev	118degrees
h8	29mm	2	296mm	175mm	131.5mm	DIN 345	3		0.25mm/rev	118degrees
h8	29.5mm	2	296mm	175mm	130.8mm	DIN 345	3		0.25mm/rev	118degrees
h8	30mm	2	296mm	175mm	130mm	DIN 345	3		0.25mm/rev	118degrees
h8	30.5mm	2	301mm	180mm	134.3mm	DIN 345	3		0.25mm/rev	118degrees
h8	31mm	2	301mm	180mm	133.5mm	DIN 345	3		0.25mm/rev	118degrees
h8	32mm	2	334mm	185mm	137mm	DIN 345	4		0.25mm/rev	118degrees
h8	33mm	2	334mm	185mm	135.5mm	DIN 345	4		0.25mm/rev	118degrees
h8	34mm	2	339mm	190mm	139mm	DIN 345	4		0.25mm/rev	118degrees
h8	35mm	2	339mm	190mm	137.5mm	DIN 345	4		0.25mm/rev	118degrees
h8	36mm	2	344mm	195mm	141mm	DIN 345	4		0.25mm/rev	118degrees
h8	38mm	2	349mm	200mm	143mm	DIN 345	4		0.25mm/rev	118degrees
h8	39mm	2	349mm	200mm	141.5mm	DIN 345	4		0.25mm/rev	118degrees
h8	40mm	2	349mm	200mm	140mm	DIN 345	4		0.32mm/rev	118degrees
h8 h8	41mm	2	354mm	205mm 205mm	143.5mm	DIN 345	4	0.32mm/rev	0.32mm/rev	118degrees 118degrees
h8 h8	42mm	2	354mm	205mm	142mm	DIN 345	4 4	0.32mm/rev	0.32mm/rev	118degrees 118degrees
h8	43mm	2	359mm	210mm 210mm	145.5mm	DIN 345	4	0.32mm/rev	0.32mm/rev	118degrees 118degrees
h8	44mm 44mm	2	359mm	210mm	144mm	DIN 345	4 4	0.32mm/rev	0.32mm/rev	118degrees 118degrees
h8 h8	45mm	2	359mm 359mm	210mm	142.5mm	DIN 345 DIN 345	4	0.32mm/rev	0.32mm/rev	118degrees 118degrees
h8	46mm 46mm	2	364mm	215mm	146mm	DIN 345	4	0.32mm/rev	0.32mm/rev	118degrees 118degrees
h8	47mm	2	364mm	215mm	144.5mm 144.5mm	DIN 345	4 4	0.32mm/rev	0.32mm/rev	118degrees 118degrees
h8	48mm	2	369mm	220mm	148mm 148mm	DIN 345	4	0.32mm/rev	0.32mm/rev	118degrees 118degrees
h8	49mm	2 2	369mm 369mm	220mm	146.5mm	DIN 345 DIN 345	4	0.32mm/rev	0.32mm/rev	118degrees 118degrees
h8	50mm	2	369mm	220mm 220mm	145mm	DIN 345	4	0.32mm/rev	0.32mm/rev	118degrees 118degrees
h8	51mm	2	412mm	225mm	148.5mm	DIN 345	5	0.32mm/rev	0.32mm/rev	118degrees 118degrees
h8	55mm	2	417mm 417mm	230mm 230mm	147.5mm	DIN 345 DIN 345	5	0.32mm/rev	0.32mm/rev	118degrees 118degrees
h8	60mm	2 2	422mm	235mm	145mm	DIN 345	5 5	0.32mm/rev	0.32mm/rev	118degrees 118degrees
h8	65mm	2	432mm	245mm 245mm	147.5mm	DIN 345	5	0.4mm/rev	0.4mm/rev	118degrees 118degrees
h8	70mm	2 2	437mm 437mm	250mm	145mm	DIN 345	5	0.4mm/rev	0.4mm/rev	118degrees 118degrees

305.61
316.47
361.72
332.21
382.34
382.34
395.02
411.77
411.77
428.79
428.79
463.90
463.90
491.37
491.37
510.86
510.86
540.57
540.57
552.41
600.01
617.06
661.75
601.44
656.67
666.68
674.44
701.82
701.82
741.01
766.95
818.12
843.32
875.06
912.32
924.27
932.13
1045.97
1096.98
1128.23
1096.98
1230.52
1293.46
1329.33
1378.19
1431.39
1513.78
1643.66
1878.21
1997.73
2010.81
2110.32
2365.34
2582.65
2764.19
3027.46
3009.52
3161.59
4040.47
4258.38
4202.62
4750.12
4918.76
5090.58
5260.60
6094.61
6680.34
9900.13
11871.48
13782.48
