| 物料号 |
| 133360 1-8 |
| 133360 1/2-13 |
| 133360 1/4-20 |
| 133360 2-56 |
| 133360 3/4-10 |
| 133360 3/8-16 |
| 133360 4-40 |
| 133360 5-40 |
| 133360 5/8-11 |
| 133360 5/16-18 |
| 133360 6-32 |
| 133360 7/8-9 |
| 133360 8-32 |
| 133360 10-24 |
| 133360 12-24 |
刀具材料 |
切刃数 Z |
切割角 |
底孔直径 |
总长度 L |
排屑槽数量 |
柄四边 □ |
柄直径 Ds |
标准 |
每英寸螺距 |
螺纹深度 |
螺纹直径 |
螺纹种类 |
螺纹规格 |
螺距 |
HSS E PM
4
8degrees
22.25mm
160mm
4
14.5mm
18mm
DIN 376
8
76.2mm
25.4mm
UNC
1-8 UNC
3.175mm
| ||||||||||||||
HSS E PM
3
8degrees
10.8mm
110mm
3
7mm
9mm
DIN 376
13
38.1mm
12.7mm
UNC
1/2-13 UNC
1.95mm
| ||||||||||||||
HSS E PM
3
8degrees
5.1mm
80mm
3
5.5mm
7mm
DIN 371
20
19.05mm
6.35mm
UNC
1/4-20 UNC
1.27mm
| ||||||||||||||
HSS E PM
2
8degrees
1.85mm
45mm
2
2.1mm
2.8mm
DIN 371
56
6.54mm
2.18mm
UNC
2-56 UNC
0.453mm
| ||||||||||||||
HSS E PM
3
8degrees
16.5mm
125mm
3
11mm
14mm
DIN 376
10
57.15mm
19.05mm
UNC
3/4-10 UNC
2.54mm
| ||||||||||||||
HSS E PM
3
8degrees
8mm
100mm
3
8mm
10mm
DIN 371
16
28.59mm
9.53mm
UNC
3/8-16 UNC
1.587mm
| ||||||||||||||
HSS E PM
2
8degrees
2.35mm
56mm
2
2.7mm
3.5mm
DIN 371
40
8.52mm
2.84mm
UNC
4-40 UNC
0.635mm
| ||||||||||||||
HSS E PM
3
8degrees
2.65mm
56mm
3
2.7mm
3.5mm
DIN 371
40
9.51mm
3.17mm
UNC
5-40 UNC
0.635mm
| ||||||||||||||
HSS E PM
3
8degrees
13.5mm
110mm
3
9mm
12mm
DIN 376
11
47.64mm
15.88mm
UNC
5/8-11 UNC
2.309mm
| ||||||||||||||
HSS E PM
3
8degrees
6.6mm
90mm
3
6.2mm
8mm
DIN 371
18
23.82mm
7.94mm
UNC
5/16-18 UNC
1.411mm
| ||||||||||||||
HSS E PM
3
8degrees
2.85mm
56mm
3
3mm
4mm
DIN 371
32
10.53mm
3.51mm
UNC
6-32 UNC
0.794mm
| ||||||||||||||
HSS E PM
3
8degrees
19.5mm
140mm
3
14.5mm
18mm
DIN 376
9
66.69mm
22.23mm
UNC
7/8-9 UNC
2.822mm
| ||||||||||||||
HSS E PM
3
8degrees
3.5mm
63mm
3
3.4mm
4.5mm
DIN 371
32
12.48mm
4.16mm
UNC
8-32 UNC
0.794mm
| ||||||||||||||
HSS E PM
3
8degrees
3.9mm
70mm
3
4.9mm
6mm
DIN 371
24
14.49mm
4.83mm
UNC
10-24 UNC
1.058mm
| ||||||||||||||
HSS E PM
3
8degrees
4.5mm
80mm
3
4.9mm
6mm
DIN 371
24
16.47mm
5.49mm
UNC
12-24 UNC
1.058mm
|
| 销售价 | 数量 |
HSS-E-PM 切削材料，保证最高耐磨性。
全新高性能涂层降低摩擦系数。
专用槽型保障理想的排屑效果。
