| 物料号 |
| 137868 1/2-13 |
| 137868 1/4-20 |
| 137868 3/4-10 |
| 137868 3/8-16 |
| 137868 4-40 |
| 137868 5/8-11 |
| 137868 5/16-18 |
| 137868 6-32 |
| 137868 7/16-14 |
| 137868 8-32 |
| 137868 10-24 |
刀具材料 |
切刃数 Z |
切割角 |
底孔直径 |
总长度 L |
排屑槽数量 |
柄四边 □ |
柄直径 Ds |
标准 |
每英寸螺距 |
螺纹直径 |
螺纹种类 |
螺纹规格 |
螺距 |
HSS E
3
15degrees
10.8mm
110mm
3
7mm
9mm
DIN 376
13
12.7mm
UNC
1/2-13 UNC
1.954mm
| |||||||||||||
HSS E
3
15degrees
5.1mm
80mm
3
5.5mm
7mm
DIN 371
20
6.35mm
UNC
1/4-20 UNC
1.27mm
| |||||||||||||
HSS E
4
15degrees
16.5mm
125mm
4
11mm
14mm
DIN 376
10
19.05mm
UNC
3/4-10 UNC
2.54mm
| |||||||||||||
HSS E
3
15degrees
8mm
100mm
3
7mm
9mm
DIN 371
16
9.53mm
UNC
3/8-16 UNC
1.587mm
| |||||||||||||
HSS E
3
15degrees
2.35mm
56mm
3
2.7mm
3.5mm
DIN 371
40
2.84mm
UNC
4-40 UNC
0.635mm
| |||||||||||||
HSS E
3
15degrees
13.5mm
110mm
3
9mm
12mm
DIN 376
11
15.88mm
UNC
5/8-11 UNC
2.309mm
| |||||||||||||
HSS E
3
15degrees
6.6mm
90mm
3
6.2mm
8mm
DIN 371
18
7.94mm
UNC
5/16-18 UNC
1.411mm
| |||||||||||||
HSS E
3
15degrees
2.85mm
56mm
3
3mm
4mm
DIN 371
32
3.51mm
UNC
6-32 UNC
0.794mm
| |||||||||||||
HSS E
3
15degrees
9.4mm
100mm
3
6.2mm
8mm
DIN 376
14
11.11mm
UNC
7/16-14 UNC
1.814mm
| |||||||||||||
HSS E
3
15degrees
3.5mm
63mm
3
3.4mm
4.5mm
DIN 371
32
4.16mm
UNC
8-32 UNC
0.794mm
| |||||||||||||
HSS E
3
15degrees
3.9mm
70mm
3
4.9mm
6mm
DIN 371
24
4.83mm
UNC
10-24 UNC
1.058mm
|
