| 物料号 |
| 261352 8/05 |
| 261352 10/07 |
| 261352 12/07 |
| 261352 16/07 |
| 261352 16/11 |
| 261352 20/11 |
| 261352 25/16 |
ISO 代码 刀杆 |
中心偏差 L3 |
主偏角 κ |
刀片尺寸 |
可转位刀片布置 |
头部长度 L1 |
夹紧高度 L2 |
已复位支架的悬伸长度 L1 |
总长度 L |
接口 / 接头 |
最小预钻孔直径 Dmin |
有效深度 T |
柄直径 Ds |
转位刀片螺栓套件 |
配套适用的转位刀片 |
颈部宽度 L4 |
A08F SVVCR/L05
5.5mm
72.5degrees
5mm
15mm
7.5mm 7.5mm
15mm
80mm
8mm
10.2mm 10.2mm
3.5mm 3.5mm
8mm 8mm
269028 26
VC..0501..
6mm
| |||||||||||||||
A10H SVVCR/L07 A10H SVVCR/L07
8mm 8mm
72.5degrees
7mm
22mm
9mm 9mm
22mm
100mm
10mm
13.5mm
6mm 6mm
10mm 10mm
269028 27
VC..0702..
6.8mm
| |||||||||||||||
A12K SVVCR/L07
9mm
72.5degrees
7mm 7mm
28mm
11mm
28mm
125mm 125mm
12mm
15.5mm
6mm 6mm
12mm 12mm
269028 27 269028 27
VC..0702.. VC..0702..
9mm 9mm
| |||||||||||||||
A16M SVVCR/L07
11mm
72.5degrees 72.5degrees
7mm
36mm
15mm
36mm
150mm
16mm
19.5mm
6mm 6mm
16mm 16mm
269028 27 269028 27
VC..0702..
12.9mm 12.9mm
| |||||||||||||||
A16M SVVCR/L11
14mm
72.5degrees
11mm
左 和 中性
15.5mm
40mm
150mm
16mm
23mm
9.5mm
16mm
269028 22
VC..1103..
11.9mm
| |||||||||||||||
A20Q SVVCR/L11
14mm
72.5degrees
11mm
左 和 中性
19mm
50mm
180mm
20mm
25mm
9.5mm
20mm
269028 22
VC..1103..
13.9mm
| |||||||||||||||
A25R SVVCR/L16
20mm
72.5degrees
16mm
左 和 中性
23mm
62.5mm
200mm
25mm
34mm
13mm
25mm
269028 8
VC..1604..
19.5mm
|
